Special Instrument Item Series
Reliable Safety Instrument Series
Alcohol Tester
Instruments
AC-II
Features:
Display LED (flashing) acoustic Sound Signal
Auto Power Off (APO 5 minutes)
Bright White LED Flash Light.
POWER:
AAA 1.5V X 2
Dimension: 145(H) x 25(W) x 21(D) mm
Weight: Approx 42g
Technical Data:
| Basic Functions | Volt Detect AC-II |
|---|---|
| Voltage Range | 90~1000 VAC |
| IP – Protection | IP40 |
| Overvoltage Category | CAT IV, 1000V |
ST 852
Features:
Operational Voltage: 200~480V (3 Phase AC)
Withstand Voltage: 4000V for 1 minute
Measuring Frequency Range: 20~400Hz
Time Limit for Continuous measurement:
1. Less than 60 minutes at 200 VAC
2. Less than 40 minutes at 400 VAC
Standard Accessories: Test Lead (attached to meter), Alligator Clips, Carrying Case, Manual
Dimension: 85(H) × 64(W) × 23(D) mm
Technical Data:
| Measuring Result | Open Phase Check by LED | Phase Order Check by LED | Buzzer |
|---|---|---|---|
| Current Phase (CW) | All 3 Orange LED are Lit | Green LED is Lit | Intermittent beep |
| Reverse Phase (CCW) | All 3 Orange LED are Lit | Red LED is Lit | Continuous beep |
| Open Phase (One Phase Only) | Orange LED for Open Phase are off | Both Green & Red LED are off | – |
AC-IV
Features:
Display LCD with Bargraph
Backlight Red & Green Double Colour
Signal Intensity four level
- Flash Light No operation sensing signal will shutdown
- Auto Power Off (APO 3 minutes)
POWER:
AAA 1.5V × 2
Dimension: 157(H) × 27(W) × 23(D) mm
Weight: Approx 32 g
Technical Data:
| Basic Functions | Volt Detect AC IV |
|---|---|
| Voltage Range (Sensitivity) | High 12 ~ 1000V / Low 48 ~ 1000V |
| IP – Protection | IP 40 |
| Overvoltage Category | CAT III 1000V |
ST 852
Features:
Compact, easy-to-wear and convenient to use.
Indoor and outdoor use
Equipped with self-testing functions.
Audio indications.
Able to sense a wide variety of AC high Voltage systems.
- Low power consumption.
Specification:
Initial Warning Distance :
• 220V~380V : 0.1m~0.4m
• 10kV : 0.7m~1.2m
• 35kV : 1m~2mFrequency : 50 / 60 HZ
Volume : 75 dB at 1 m
Battery Life : 50 Hrs. of Cont. Use
Dimension : 52(W), 60(H), 21mm thick
- Power : AAA 1.5V × 2
- Safety Standards : EN 61326 – 1
- Manual Instruction
MECO DIT 945PI Insulation Resistance Tester
- Insulation Test Voltages: 250V, 500V, 1000V, and
2500V. - Insulation Resistance Range:
250V/500V/1000V: Up to 20GΩ
2500V: Up to 200GΩ - AC Voltage Range: Up to 600V AC
- Low Resistance Range: Up to 60Ω
- Display: 4-digit (2000 counts) large LCD with
backlight - Safety Standards:
IEC/EN 61010-1
CAT II 1000V
CAT III 600V
Special Instrument Items
R-tek Digital Vernier Caliper
- Measuring Range: The caliper shown is a 150mm model, but R-tek also makes 200mm and 300mm models. 0-150mm / 0-6 inches Resolution: 0.01mm / 0.0005 inches
- Accuracy: ±0.02mm
- Material: Hardened stainless steel
- Display: Extra large LCD screen
- Power: One 1.55V button cell (likely a SR44 or LR44)
- Four Measurement Functions: The caliper can be used to measure: 1. External dimensions (outer jaws) 2. Internal dimensions (inner jaws) 3. Depth (depth probe) 4. Step measurement (the stepped face at the end of the caliper
Grain Moisture Meter
Grain Moisture Meter LSKC-608 Seed/Grain Moisture Meter
Features:
- GRAIN: Paddy, Rice, Corn, Wheat.
- Display: 4 digits, 10mm LCD.
- Range: Moisture Content: 8–20%, Temp.: 10–65°C.
- Accuracy: Moisture: ±1%, Temp.: ±0.8, Resolution: 0.1.
- Operating Temperature: 0–50°C or 32– 122°F.
- Operating Humidity: < 0.8.
- Battery: 4 × 1.5AA (um-3).
- Size: 178 × 68 × 39mm.
- Weight: 190g (not including measuring probe and batteries).
Special Instruments
L.T.I. MD-2G Moisture Meter
- Display: LCD
- Measuring Range: Wood: 5% to 42% Hardened materials (mortar, concrete, plaster): 0.2% to 2.0%
- Accuracy:
- Wood: ±2% (for readings less than 30%) and ±4% (for readings equal to or greater than 30%)
- Materials: ±0.1% (for readings less than 1.4%) and ±0.2% (for readings equal to or greater than 1.4%) Resolution: 1%
- Operating Temperature & Humidity: 0°C to 40°C (32°F to 104°F), < 85% RH
- Storage Temperature & Humidity: -10°C to 50°C (14°F to 122°F), < 85% RH
- Power Supply: 4 x 1.5V LR44 button cells or 1 x 9V (6F22) battery. The specific model in the image appears to use the 9V battery based on similar products. Auto Power Off: Yes, after 15 seconds of no key operation.
- Dimensions: 80 x 40 x 20 mm
- Weight: Approximately 50 g (including batteries)
- Probe: Two 7 mm steel pins attached to the top of the meter.
G-TECH GT-291 Digital Moisture Meter
- Model: GT-291 Brand: G-TECH Measuring Range: Wood (4 grades): 7.2% – 70% Building materials (3 grades): 0% – 15.2%
- Display: Large LCD screen with backlight Digital percentage moisture reading
- Accuracy: ±2% (depending on material and conditions) Resolution: 0.1% moisture
- Functions: Data Hold (freeze reading on display) Auto/Manual Power Off Low Battery Indication Backlight for dark environments
- Operating Conditions: Temperature: 0°C ~ 40°C Humidity: 0 ~ 85% RH (non-condensing)
- Power Supply: 1 × 9V battery
- Dimensions: Approx. 145 × 60 × 30 mm Weight: ~180g (with battery)
2000V AND 2000A DC/ACTRMS Digital Clampmeter
- 2000V &2000A AC/DC
- Auto/ Mannual Ranging
- Resistance, Capacitance
- Backlight + Torch Light
- Inrush Current
- Diode Test, Audible Continuity, Data Hold
- Auto pwer off
Technical Specifications:
- Model: MS-02 Brand: HTC Instruments Measurement Principle: Electrical resistance (pin-type) Measurement Range (Wood Moisture): 6% – 99.9% (depending on wood type)
- Temperature Range: 0°C ~ 40°C (operating) Temperature Unit Selection: °C / °F switchable Accuracy (Moisture): ±2% (typically within range)
- Resolution: 0.1% (Moisture), 0.1°C / 0.1°F (Temperature) Display: Large LCD with backlight Displays moisture %, temperature, MAX/MIN, HOLD Wood Group Selection: Multiple wood species groups (A–H) programmable
- Power Supply: Battery: 2 × 1.5V AAA batteries Physical Characteristics: Dimensions: Approx. 135 × 50 × 25 mm Weight: ~150g (with battery) Material: ABS plastic body with protective cap
Digital Earth Resitance Tester
- 3.5 DIgit/1999Counts
- Two Rangesfor Earth Resistance Measurements
- 0-100 Ohms / 1000Ohms
- Earth Voltage 0-10V AC
- Range selection and single push Button operation switches
- Function icons on display
- Designed to generally confirm to IS 10656-1983
- IEC 1010CAT III 200V
Digital Earth Resitance Tester
- Model: DIT 945Pi
- Type: Insulation Resistance Tester
- Test Voltage: Up to 2.5 kV (2500V)
- Resistance Range: Up to 200 GΩ
- Low Resistance Range: Up to 60 Ω
- Safety Ratings:
- CAT III 1000V
- CAT IV 600V
